WP150

New silent pile press to Kowan Still Worker WP-150 together with power pack TE-200 and ballast extra weight and hydraulic hoses.
Technical specification:
Pile press WP-150
Max pressing in force: 1 500 kN
Max pressing out force: 1 600 kN
Stroke: 800 mm
Pressing in speed: 1.8 ÷ 23.0 m/min
Pressing out speed: 1.9 ÷ 18.0 m/min
Tilting device: ± 5 °
Mast rotation: 180 °
Used profiles: "U" type i 400, 500 and 600 mm
Operation: cable control and remote control
Self-moving
Total weight (without clamp): 9 500 kg
Dimensions: 2455 x 1140 x 2580 mm
Power pack TE-200
Engine: Diesel, 4 cylinders, water cooled, turbocharged with direct injection
Power: 141.1 kW at 1800 rpm
Oil flow: variable capacity
Max pressure: 40 MPa
Oil tank capacity: 350 l
Fuel tank capacity: 550 l
Dimensions: 3300 x 1380 x 1700 mm
Weight: 5 300 kg
Ballast extra weight of WP-150
Dimensions: 3200 x 1900 x 475 mm
Weight: 1700 kg
Delivery includes:
Pile press WP-150
Ballast extra weight of WP-150
Hydraulic hoses
Power pack TE-200
Net price, VAT should be added, if applicable.
