CNC External Grinder Waldrich Siegen model WS1

CNC External cylindrical milling Waldrich Siegen mod. WS1
Manufacturer: WALDRICH SIEGEN
Model: WS1 h-sp 50x8000
YOM: Retrofitted in 2009
CNC: Siemens
Share
Ask for price On request
Condition Used - Working

Machine data

Machine data
Condition Used - Working
Price type On request

Technical specifications

Technical specifications
Weight 50.000 kg
Length 8.000 mm
Grinder type Cilindrica
Wheel diameter 900 mm
X travel 700 mm
Control type CNC
Spindle power 74,60 kW

Occasional seller

M
Metalequip Private seller
Member since 2017
40 ads online

SEND REQUEST

CNC External Cylindrical Grinding Waldrich Siegen mod. WS1
Manufacturer: WALDRICH SIEGEN
Type: WS1 h-sp 50x8000
YOM: Retrofitted in 2009
CNC: Siemens
CAPACITY:
Maximum roller diameter to grind with
900 mm diameter wheel: 1500 mm
800 mm diameter wheel: 1800 mm
Minimum roller diameter to grind with
900 mm diameter wheel: 100 mm
Total roller length: 8000 mm
Maximum workpiece weight: 50 tons
HEADSTOCK:
Drive motor output: 15-60-60 HP
Motor speeds, infinitely variable: 180-720-1800 r.p.m.
Faceplate speeds: 6-60 r.p.m.
Starting motor output: 15 HP
GRINDING CARRIAGE:
Grinding carriage feed, infinitely variable: 60-4000 mm/min
Feed motor output: 8.5 HP
Motor speeds, infinitely variable: 24-1600 r.p.m.
Cross travel of the upper rest: 700 mm
Grinding wheel motor output: 100 HP
Motor speeds, infinitely variable: 500-1000-2000 r.p.m.
Grinding spindle speeds: 400-1600 r.p.m.
WHEELS:
Diameter: 900 mm
Width: 90 mm
Diameter: 305 mm

  • Seller's country: Polonia
  • State: Used - Functional
  • Weight: More than 10,000 kg
  • Long: More than 5,000 mm
  • Width: Up to 1,000 mm
  • Control type: CNC
  • X Travel: 500 - 1,000 mm
  • Spindle power: More than 30 kW
  • Type of grinding machine: Cylindrical
  • Wheel diameter: More than 600 mm
  • Condition: Array
  • Weight: 0.000000
