660X20 ERW API

Tube Mill Manufacturing Line, Tube Manufacturing Line, Linha de fabricação de tubos, Ligne de fabrication, Tube Mill

660 X 20 mm ERW API & con, com, avec, with

Slitting Machine, Linha de corte longitudinal, Ligne de coupe longitudinale, Slitter: 2200X20


Year of manufacture, Ano de fabricação, Année de fabrication, Year manufactured: 2011

Stop year, Ano de parada, Année d'arrêt, Stop production: 2015

Installed, Instalado, Installé, In line: Yes, sim, oui, yes

Condition, Conservação, État de conservation, Work conditions: Ok

Thickness, Espessura, Épaisseur, Thickness: 5…..20/22 mm

Coil width, Largura da bobina, Largeur de bobine, Coil width: 618-2100 mm

Coil weight, Peso da bobina, Poids de bobine, Coil weight: 35 tons

Steel grade, Qualidade do aço, Qualité d'acier, Steel grade: < = X80

Diameter R, Diâmetro R, Diamètre R, Diameter R: φ 273-660mm

Length, Comprimento, Longueur, Length: 11.5-12 mt.

Ultrasonic in-line, Ultra-sons on-line, Ultrasons en ligne, Ultrasonic in-line: Yes, sim, oui, yes

HF Welding Equipment, Soldador de alta frequência, Soudeur à haute fréquence, Welder HF: 1800 KW



Other machines included / Outras máquinas incluídas / Autres machines incluses / Others machines included:

Beveler, Máquina de chanfrar, Machine de chanfreinage, Beveler

Hydrostatic test, Teste hidráulico, Essai hydraulique, Hydrostatic tester

Transit rollers, Rolos de transporte, Rouleaux de transport, Transit conveyors

Slitting Machine, Linha de corte longitudinal, Ligne de coupe longitudinale, Slitter: 2200X20

----------------------------------------------------------------------------------------------------------------------------------------------------------

Remaining mill equipment, Equipamento da máquina de fabricação, Équipement de la machine de fabrication, Mill Equipment



Manufacturing flow, Fluxo de fabricação, Flux de fabrication, Manufacturing flow

Coil car & prep table

Uncoiler

Peeler

Pinching roller

Pinch roller

Cut end & welder

Transit roller table

5-roll leveler

7-roll leveler

Spiral accumulator with in/out twist stands

Pinch roll

Forming stands (Spindle: φ320 mm)

4 - Seam Annealer (4 × 600 KW IF induction seam annealer)

2 - Bead trimmer with scrap rewinder

1800 KW Welder (Solid state HF welder)

Welder box

Turks Head (Two stands)

Sizing stands

Water cooling trough

Air cooling racks

Hydrotester / Beveler

Transit conveyors

Run-out racks

Flying cut-off saw

Huaye is capable of offering you a complete service: designs, manufacturing, construction, installation, commissioning, training, and warranty.
Huaye is able to offer you a complete service: design, manufacture, construction, installation, commissioning, teaching and warranty.
Huaye is able to offer you a complete service: design, manufacture, construction, installation, commissioning, training and warranty.

Huaye is able to offer you a complete service of: design, manufacture, construction, installation, commissioning, teaching and warranty


Visit our website www.huaye.eu for more types of machines or write us an email to: info@huaye.eu, including your needs.
Visit our website www.huaye.eu for more types of machines or write us an email to: info@huaye.eu, including your needs.
Visit our website www.huaye.eu for more types of machines or write us an email to: info@huaye.eu, including your needs.

Visit our website www.huaye.eu for more types of machines or write us an email to: info@huaye.eu, including your needs.
