5A872

Stanko
Spiral bevel gear grinding machine 5A872 - workpiece diameter 800 x module 16 mm - STANKO
Share
Ask for price On request
Condition Used - Working

Machine data

Manufacturer STANKO
Condition Used - Working
Price type On request

Technical specifications

Weight 12.500 kg
Length 3.320 mm
Width 2.100 mm
Height 2.000 mm

Occasional seller

S
STANKOTRADING Private seller
Member since 2017
14 ads online

SEND REQUEST

5A872
5A872
5A872

Gear grinding machine for spiral bevel gears, model 5A872
Manufacturer: STANKO
Condition: perfect, accessories, can be inspected under power.
- workpiece diameter, mm 800
- module, mm 16
- number of teeth 4-100
- spiral angle, degrees 0-60
- tooth depth, mm 33
- ring or pinion width, mm 125
- cradle roll, degrees 0-60
- grinding wheel diameter, mm 160; 250; 315; 450
- spindle speed, RPM 955-4140
- machine dimensions (LxWxH), mm 3320x2100x2000
- machine weight, kg 12500

  • Seller's country: Rusia
  • State: Used - Functional
  • Weight: More than 10,000 kg
  • Long: 3,000 - 5,000 mm
  • Width: 2,000 - 3,000 mm
  • High: 1,500 - 2,500 mm
  • Condition: Array
  • Weight: 0.000000
