W200A

Horizontal drilling machine W200A - spindle 200, X-4000 Y-4000 Z-2000 + 1600 table E-20 - SKODA
Share
Ask for price On request
Condition Used - Working

Machine data

Machine data
Manufacturer skoda
Condition Used - Working
Price type On request

Technical specifications

Technical specifications
Weight 86.200 kg
X travel 4.000 mm
Y travel 4.000 mm
Z travel 1.600 mm
Spindle power 77 kW

Occasional seller

S
STANKOTRADING Private seller
Member since 2017
14 ads online

SEND REQUEST

Horizontal milling and boring machine W200A
Manufacturer: SKODA
Condition: The machine is in good working condition, can be verified under power
Equipped with: The machine is equipped with rotary table E-20 2200 x 2200 mm, capacity 20 tn. + angular heads (as additional equipment, the machine can be equipped with a rotary table of 3600 x 3600 mm, with a capacity of 50 tons)
Spindle diameter, mm 200
Spindle torque, Nm 35000
Main motor power, kW 77
X-axis (column), mm 4000
Y-axis (headstock), mm 4000
Z-axis (spindle), mm 1600
W-axis (ram), mm 2000
Ram size, mm 520 x 520
Bed width, mm 2000
Machine weight, kg 86200
STANKOTRADING company. REVIEW OF METALWORKING EQUIPMENT.
ENGINEERING CONSULTANCY, SUPPLY AND MAINTENANCE OF MACHINES.

  • Seller's country: Rusia
  • State: Used - Functional
  • Weight: More than 10,000 kg
  • X Travel: More than 3,000 mm
  • Y travel: More than 1,000 mm
  • Z travel: More than 800 mm
  • Spindle power: More than 30 kW
  • Condition: Array
  • Weight: 0.000000
