SL150

MORI SEIKI SL 150 LATHE WITH Y-AXIS AND
Main features:
-12-station motorized turret
-Y-axis
-Main spindle and subspindle
-210 mm main chuck
-Chip conveyor
-Presetter
-Swing over bed 620 mm
-Swing over cross slide 455 mm
-Maximum turning diameter 430 mm
-Distance between centers 560 mm
-Bar capacity 45 mm
-Spindle bore 56 mm
-X-axis travel 230 mm
-Z-axis travel 520 mm
-Y-axis travel 70 +40/-30 mm
-Headstock up to 5,000 rpm
-Motorized tools up to 3,000 rpm
-In the photo, the subspindle is protected with a nylon plug to
prevent dirt from entering (it also has the chuck)
-It has 5 motorized tools.
